Thursday, March 24, 2011

Upgrading oracle Database from to on Windows Server

I've upgraded the Database to are the steps with screenshots on the right side for our reference.I have downloaded the PATCH SET and applying it to my current Database release

Step 1: I’m doing this upgrade by Checking the version initially (

SQL>select name from v$database;
SQL>select *from v$version; =>Database version is as seen in screenshot1.

Step 2:Login to you’re MY ORACLE SUPPORT account =>Click on PATCHES & UPDATES for downloading your patch for Windows 32-bit Operating system(which can
Refer in the screenshot1 in step 1)
In PATCHES & UPDATES =>enter patch number 6810189
You can select upto 5 operation systems but to reduce your search select windows
32 bit as you can see in the screenshot2.

Now,download this patch set .Refer the screenshot 3 for the better overview:

Step 3: Shutdown the oracle Database.

Click on the Read Me tab and save the Read me file so that you can refer this later while doing patch installation.When you are doing this upgrade fro RAC Database the steps may vary which is given in this Read me file.

Step 4: Now download this this patch and copy it to D:\soft 10.4\ path(This can be a place in your ORACLE_HOME Directory or not necessary) But for my reference I copied here.

Set the SID and Shutdown the database as given in the screenshot4.

Step 5: Stop all the services now
My service name is BOSCHDB So I will be stopping the services as given below:

D:\Oracle10g>net stop OracleDBConsoleBOSCHDB

The OracleDBConsoleBoschDB service is stopping........
The OracleDBConsoleBoschDB service was stopped successfully.

D:\Oracle10g>net stop OracleServiceBOSCHDB

The OracleServiceBOSCHDB service is stopping.
The OracleServiceBOSCHDB service was stopped successfully.

D:\Oracle10g>lsnrctl stop

Step 6:Backup your database.

As a precaution or Primary responsibility of DBA and also
Oracle recommends that you create a backup of the Oracle 10g installation before you install the patch set.

Step 7:Check Tablespace Sizes and Set Parameter Values if require
Review the following sections before upgrading a database.

Step 8:Now Launch your setup by going to the path where this patch is copied

cd D:\soft 10.4\Disk1
D:\soft 10.4\Disk1>setup.exe

Specify the location of your Oracle home by Browse:

Create a separate folder (Directory) as below:

I was happy to see this screen where I have to click install

Step9: Upgrade the Database

After you install the patch set, you must perform the following steps on every database associated with the upgraded Oracle home:

Start all services
Go to Control panel=>Administrative tools =>Services=>Start all oracle services as given below or In Start=>run=>services.msc

Step 10: Upgrade your dictionary

SQL> SPOOL patch.log

This script provides a direct upgrade path from these releases to the new Oracle release.

Note 1: For running catupgrd.sql you have to start your Database by using
Note 2:Catupgrd.sql script should be run by going into the above path of ORACLE_HOME/rdbms/admin

Once this script is executed successfully you will see the screen as given below

Step 11:Bounce(restart) your Database for changes to take effect:


Step 12: Compile Invalid Objects & Verify our
Database version.

Run the utlrp.sql script to recompile all invalid PL/SQL packages.

SQL> @ D:\Oracle10g\RDBMS\ADMIN\utlrp.sql

SQL> select * from v$version;

Oracle Database 10g Enterprise Edition Release - Prod
PL/SQL Release - Production
CORE Production
TNS for 32-bit Windows: Version - Production
NLSRTL Version - Production

Hope it helps.
